Isolator, DC 24V 1 in 1 Out Analog Current Isolator, 4-20mA Output, 100 * 22.5 * 114.5mm

Specification: Model: WS90601 Power supply voltage :DC 24 (V) ±10% Current consumption: ≤70mA Channel configuration: one in one out Input : K type thermocouple (0-1300 ℃) Output : 4-20mA The output load resistance: RL≤500Ω (the output for the current ); RL≤10 K (output voltage ) Operating temperature range: -20℃ to + 55 ℃ Size: 100 * 22.5 * 114.5mm / 3.9 * 0.9 * 4.5in P urpose: thermocouple transmitter, full isolation, anti - Applicable equipment: electric resistance Package List:1 x Isolator

• isolator, and
• This isolator provides isolated power distribution power supply for transmitter,meanwhile it isolates and converts the current to control room.
• The input, output and power are isolated from each other by adopting highly efficient magnetoelectric isolation technology interiorly.
• Strong input processing ability, able to accept and process thermocouple, thermal resistance, frequency and other
• Have the advantage of high ,high linearity and strong anti-interference.
